Swimming pool water supply method and other circulation methods
Published:
2025/04/24
Scientific Circulation Method for Swimming Pool - Pool Equipment-
Swimming pool water supply method and other circulation methods
Two water supply methods: horizontal water supply on the pool wall and vertical water supply at the pool bottom - pool equipment-
There are two water supply methods for swimming pools: horizontal water supply from the pool walls and vertical water supply from the pool bottom, and both water supply methods are used independently. Horizontal water supply on the pool wall is convenient for construction, installation, and operation. It is the most commonly used water supply method, but its disadvantage is uneven heat distribution and chemical addition; The biggest advantage of vertical water supply at the bottom of the pool is that the heat distribution and chemical addition are relatively uniform, but it is difficult to construct and install.
2. Scientific Circulation Method for Swimming Pool - Pool Equipment-
There are two types of water supply methods: vertical water supply from the bottom of the pool and horizontal water supply from the pool wall; There are also two types of return water methods: the skimmer with bottom discharge return water and the overflow tank with bottom discharge return water. By arranging and combining the 2 × 2 water supply and return modes, four circulation modes can be obtained, which are commonly used abroad. They are: a. The optimal circulation mode: ① Vertical water supply at the bottom of the pool, overflow tank with bottom drainage and return system. b. The most commonly used circulation method: ② Horizontal water supply on the pool wall, and a bottom discharge and return water system with a skimmer. c. Available circulation methods: ③ Vertical water supply at the bottom of the pool, and a bottom discharge and return system with a skimmer. ④ The pool wall provides horizontal water supply, and the overflow tank is equipped with a bottom drainage and return system- Swimming Pool Equipment-
Conclusion: The scientific way of circulation is to ensure that all pollutants with different densities flow through the circulation filtration system, and then intercept, stratify, and remove them. If the water surface of the swimming pool does not circulate, the water surface is a stagnant area; If there is no circulating flow at the bottom of the pool, it is a stagnant water zone. The two situations of stagnant water on the water surface and stagnant water at the bottom of the pool occur in our downstream and upstream circulation methods, which should be avoided in foreign countries.
In the circulating filtration system of swimming pools, the balance water tank, balance water tank, filtration medium, and biofilm on the inner wall of pipe valves are important links that China has not paid attention to in swimming pool water treatment, and physical and chemical treatment should be used for treatment. The traditional co current circulation mode, counter current circulation mode, and mixed flow circulation mode in China have not considered the treatment of this biofilm, and these three circulation modes have varying degrees of impact and hindrance on the treatment of equilibrium water tanks or equilibrium water tanks in terms of structure and construction- Swimming Pool Equipment-
In the practice of swimming pool engineering abroad, the return water method of skimmer with bottom drain does not require a balanced water tank. Only when the return water method of overflow tank with bottom drain is used, a balanced water tank is used, which can facilitate physical treatment (such as sewage suction) and chemical treatment (adding disinfectants, flocculants, and conducting chemical shock treatment).
